Lifting device series
eT-Hover-panel

Downloads:

The vac­u­um lift­ing de­vices in the eT-Hov­er-pan­el se­ries are de­signed for the hor­i­zon­tal lift­ing of vac­u­um-tight pan­els, such as sheet met­al, plas­tic pan­els, dense wood­en boards, etc. De­pend­ing on the frame and equip­ment used, the de­vices have a max­i­mum car­ry­ing ca­pac­i­ty of up to 4,000 kg.

They have a vari­able num­ber of cross beams. De­pend­ing on the ap­pli­ca­tion, ad­di­tion­al beams with ad­di­tion­al suc­tion plates can be used to in­crease the car­ry­ing ca­pac­i­ty (see table).


Ex­am­ple: eT-Hover-panel-250
Ini­tial car­ry­ing ca­pac­i­ty: 250 kg,
1 main beam with 2 cross beams
--------------------------------------------------------------
+ 1 ad­di­tion­al cross beam = 250 kg + 125 kg
= 375 kg car­ry­ing ca­pac­i­ty

The de­vices with an ini­tial car­ry­ing ca­pac­i­ty of up to 750 kg are op­tion­al­ly avail­able with an ex­tra-flat de­sign. Equipped with a their tele­scop­ic ma­nip­u­lat­ing han­dle bar with an op­er­at­ing pan­el, this va­ri­ety is in­tend­ed es­pe­cial­ly for re­mov­ing loads from nar­row high-bay racks. The op­er­at­ing pan­el can be used to con­trol all rel­e­vant pro­cess­es if the us­er de­sires. A vac­u­um pump with in­te­grat­ed non-re­turn valve gen­er­ates the vac­u­um.
